Electrode for Hardfacing

Characteristics and Applications Normally, it can be used in parts surfacing under room temperature and no corrosion condition. As carbon content is high and toughness is poor, basic structure steel is preferred as backing during welding. It is suitable for the parts under conditions of abrasion and impact loading, such as surfacing or repairing welding for bulldozer blades, shovel tooth, hydraulic machinery and mining machinery. Typical Chemical Composition of Weld Metal Alloy wt% C Mn Si Ni Cr Mo AWS - - - - - - EXP 0.45 0.75 1.86 - 8.20 0.56 Typical Hardness of Weld Metal HRC=47 Notes on Usage Dry 1hour under 300-350°C before use.Moisture, rust, oil stain in base metal surface should be fully removed.Proper preheating under 150-250°C, appropriate inter-pass temperature should be kept when multi-layer surfacing is proceeded.Pay attention to the pose of arc starting and arc retreating.. Sizes Available and Recommended Parameters: Diameter (mm)3.2×3504.0×4005.0×400Amp80-120 120-170160-210
